PX4实战之旅（三）：通过OFFBOARD模式控制无人机自主飞行
固件：PX4 1.13.1在目录下新建文件夹在文件夹下新建下面四个文件新建SRCS)新建Kconfigdefault n新建{return 0;}{/*if (!return 1;}if (!return 0;}{int ch;break;case '?':break;}}}}}{}{
·
前言
固件：PX4 1.13.1
一、添加自定义模块
在PX4-Autopilot/src/modules目录下新建control_node文件夹
在control_node文件夹下新建下面四个文件
新建CMakeLists.txt，复制下面内容进去：
px4_add_module(
MODULE modules__control_node
MAIN control_node
SRCS
control_node.cpp
)
新建Kconfig，复制下面内容进去：
menuconfig MODULES_CONTROL_NODE
bool "control_node"
default n
---help---
Enable support for control_node
新建control_node.cpp，复制下面内容进去：
#include "control_node.h"
#include <px4_platform_common/getopt.h>
#include <px4_platform_common/log.h>
#include <px4_platform_common/posix.h>
#include <uORB/topics/parameter_update.h>
int ControlNode::print_status()
{
PX4_INFO("Running");
// TODO: print additional runtime information about the state of the module
return 0;
}
int ControlNode::custom_command(int argc, char *argv[])
{
/*
if (!is_running()) {
print_usage("not running");
return 1;
}
// additional custom commands can be handled like this:
if (!strcmp(argv[0], "do-something")) {
get_instance()->do_something();
return 0;
}
*/
return print_usage("unknown command");
}
int ControlNode::task_spawn(int argc, char *argv[])
{
_task_id = px4_task_spawn_cmd("module",
SCHED_DEFAULT,
SCHED_PRIORITY_DEFAULT,
1024,
(px4_main_t)&run_trampoline,
(char *const *)argv);
if (_task_id < 0)
{
_task_id = -1;
return -errno;
}
return 0;
}
ControlNode *ControlNode::instantiate(int argc, char *argv[])
{
int example_param = 0;
bool example_flag = false;
bool error_flag = false;
int myoptind = 1;
int ch;
const char *myoptarg = nullptr;
// parse CLI arguments
while ((ch = px4_getopt(argc, argv, "p:f", &myoptind, &myoptarg)) != EOF)
{
switch (ch)
{
case 'p':
example_param = (int)strtol(myoptarg, nullptr, 10);
break;
case 'f':
example_flag = true;
break;
case '?':
error_flag = true;
break;
default:
PX4_WARN("unrecognized flag");
error_flag = true;
break;
}
}
if (error_flag)
{
return nullptr;
}
ControlNode *instance = new ControlNode(example_param, example_flag);
if (instance == nullptr)
{
PX4_ERR("alloc failed");
}
return instance;
}
ControlNode::ControlNode(int example_param, bool example_flag)
: ModuleParams(nullptr)
{
}
void ControlNode::run()
{
//记录起始点位置
float begin_x;
float begin_y;
float begin_z;
float_t xy_rad=1;
float_t z_rad=1;
float_t yaw_rad=0.1;
//进入offboard模式并解锁
while(!should_exit())
{
_vehicle_status_sub.copy(&_status);
if((_status.nav_state==vehicle_status_s::NAVIGATION_STATE_OFFBOARD)&&(_status.arming_state==vehicle_status_s::ARMING_STATE_ARMED))
{
PX4_INFO("in offboard and armed");
break;
}
_command.target_system = _status.system_id;
_command.target_component = _status.component_id;
ocm.timestamp = hrt_absolute_time();
_vehicle_local_position_sub.copy(&_vehicle_local_position);
sp_local.x=_vehicle_local_position.x;
sp_local.y=_vehicle_local_position.y;
sp_local.z=_vehicle_local_position.z-5;
sp_local.timestamp = hrt_absolute_time();
_trajectory_setpoint_pub.publish(sp_local);
ocm.position=true;
ocm.timestamp = hrt_absolute_time();
_offboard_control_mode_pub.publish(ocm);
_command.command =vehicle_command_s::VEHICLE_CMD_DO_SET_MODE;
_command.param1=1.0f;
_command.param2=PX4_CUSTOM_MAIN_MODE_OFFBOARD;
_command.timestamp = hrt_absolute_time();
_vehicle_command_pub.publish(_command);
usleep(10000);
_command.command = vehicle_command_s::VEHICLE_CMD_COMPONENT_ARM_DISARM;
_command.param1 = 1.0f;
_command.timestamp = hrt_absolute_time();
_vehicle_command_pub.publish(_command);
}
//记录当前点的位置
_vehicle_local_position_sub.copy(&_vehicle_local_position);
begin_x=_vehicle_local_position.x;
begin_y=_vehicle_local_position.y;
begin_z=_vehicle_local_position.z;
time_tick=hrt_absolute_time();
//业务逻辑
while (!should_exit())
{
_vehicle_local_position_sub.copy(&_vehicle_local_position);
if(flag==0)//升至5米
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=begin_x;
sp_local.y=begin_y;
sp_local.z=begin_z-5;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=false;
PX4_INFO("pos 005");
}
if((flag==1)&&(abs(_vehicle_local_position.x-sp_local.x)<xy_rad)&&(abs(_vehicle_local_position.y-sp_local.y)<xy_rad)&&(abs(_vehicle_local_position.z-sp_local.z)<z_rad))//升至5米
{
if(flag2==0)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==1)&&(hrt_absolute_time()-time_tick)>1000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=begin_x+5;
sp_local.y=begin_y;
sp_local.z=begin_z-5;
sp_local.vx=(float)NAN;
sp_local.vy=(float)NAN;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=(float)NAN;
sp_local.acceleration[1]=(float)NAN;
sp_local.acceleration[2]=(float)NAN;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=false;
time_tick=hrt_absolute_time();
PX4_INFO("pos 505");
}
}
if((flag==2)&&(abs(_vehicle_local_position.x-sp_local.x)<xy_rad)&&(abs(_vehicle_local_position.y-sp_local.y)<xy_rad)&&(abs(_vehicle_local_position.z-sp_local.z)<z_rad))//升至5米
{
if(flag2==1)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==2)&&(hrt_absolute_time()-time_tick)>1000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=begin_x+5;
sp_local.y=begin_y+5;
sp_local.z=begin_z-5;
sp_local.vx=(float)NAN;
sp_local.vy=(float)NAN;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=(float)NAN;
sp_local.acceleration[1]=(float)NAN;
sp_local.acceleration[2]=(float)NAN;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=false;
time_tick=hrt_absolute_time();
PX4_INFO("pos 555");
}
}
if(flag==3&&(abs(_vehicle_local_position.x-sp_local.x)<xy_rad)&&(abs(_vehicle_local_position.y-sp_local.y)<xy_rad)&&(abs(_vehicle_local_position.z-sp_local.z)<z_rad))
{
if(flag2==2)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==3)&&(hrt_absolute_time()-time_tick)>1000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=begin_x+5;
sp_local.y=begin_y+5;
sp_local.z=begin_z-5;
sp_local.vx=(float)NAN;
sp_local.vy=(float)NAN;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=(float)NAN;
sp_local.acceleration[1]=(float)NAN;
sp_local.acceleration[2]=(float)NAN;
sp_local.yaw=1;
sp_local.yawspeed=(float)NAN;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=false;
PX4_INFO("yaw");
}
}
if(flag==4&&(abs(_vehicle_local_position.heading-sp_local.yaw)<yaw_rad))
{
if(flag2==3)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==4)&&(hrt_absolute_time()-time_tick)>1000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=begin_x+5;
sp_local.y=begin_y+5;
sp_local.z=begin_z-5;
sp_local.vx=(float)NAN;
sp_local.vy=(float)NAN;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=(float)NAN;
sp_local.acceleration[1]=(float)NAN;
sp_local.acceleration[2]=(float)NAN;
sp_local.yaw=(float)NAN;
sp_local.yawspeed=1;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=false;
PX4_INFO("yawspeed");
}
}
if(flag==5)
{
if(flag2==4)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==5)&&(hrt_absolute_time()-time_tick)>5000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=(float)NAN;
sp_local.y=(float)NAN;
sp_local.z=begin_z-5;
sp_local.vx=1;
sp_local.vy=0;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=(float)NAN;
sp_local.acceleration[1]=(float)NAN;
sp_local.acceleration[2]=(float)NAN;
sp_local.yaw=(float)NAN;
sp_local.yawspeed=(float)NAN;
ocm.position=true;
ocm.velocity=true;
ocm.acceleration=false;
PX4_INFO("alt and velocity");
}
}
if(flag==6)
{
if(flag2==5)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==6)&&(hrt_absolute_time()-time_tick)>5000000)
{
flag++;
memset(&sp_local,0,sizeof(vehicle_local_position_setpoint_s));
sp_local.x=(float)NAN;
sp_local.y=(float)NAN;
sp_local.z=begin_z-5;
sp_local.vx=(float)NAN;
sp_local.vy=(float)NAN;
sp_local.vz=(float)NAN;
sp_local.acceleration[0]=0;
sp_local.acceleration[1]=1;
sp_local.acceleration[2]=(float)NAN;
sp_local.yaw=(float)NAN;
sp_local.yawspeed=(float)NAN;
ocm.position=true;
ocm.velocity=false;
ocm.acceleration=true;
PX4_INFO("alt and acceleration");
}
}
if(flag==7)
{
if(flag2==6)
{
flag2++;
time_tick=hrt_absolute_time();
}
if((flag2==7)&&(hrt_absolute_time()-time_tick)>5000000)
{
flag++;
_command.command =vehicle_command_s::VEHICLE_CMD_DO_SET_MODE;
_command.param1=1.0f;
_command.param2=PX4_CUSTOM_MAIN_MODE_AUTO;
_command.param3=PX4_CUSTOM_SUB_MODE_AUTO_RTL;
_command.timestamp = hrt_absolute_time();
_vehicle_command_pub.publish(_command);
PX4_INFO("return");
}
}
if(ocm.position||ocm.velocity||ocm.acceleration)
{
ocm.timestamp = hrt_absolute_time();
_offboard_control_mode_pub.publish(ocm);
_vehicle_status_sub.copy(&_status);
if(_status.nav_state==vehicle_status_s::NAVIGATION_STATE_OFFBOARD)
{
sp_local.timestamp = hrt_absolute_time();
_trajectory_setpoint_pub.publish(sp_local);
// PX4_INFO("sp_local.x=%lf\n",(double)sp_local.x);
// PX4_INFO("sp_local.y=%lf\n",(double)sp_local.y);
// PX4_INFO("sp_local.z=%lf\n",(double)sp_local.z);
// PX4_INFO("sp_local.vx=%lf\n",(double)sp_local.vx);
// PX4_INFO("sp_local.vy=%lf\n",(double)sp_local.vy);
// PX4_INFO("sp_local.vz=%lf\n",(double)sp_local.vz);
}
}
usleep(100000);
parameters_update();
}
}
void ControlNode::parameters_update(bool force)
{
// check for parameter updates
if (_parameter_update_sub.updated() || force)
{
// clear update
parameter_update_s update;
_parameter_update_sub.copy(&update);
// update parameters from storage
updateParams();
}
}
int ControlNode::print_usage(const char *reason)
{
if (reason)
{
PX4_WARN("%s\n", reason);
}
PRINT_MODULE_DESCRIPTION(
R"DESCR_STR(
### Description
Section that describes the provided module functionality.
This is a template for a module running as a task in the background with start/stop/status functionality.
### Implementation
Section describing the high-level implementation of this module.
### Examples
CLI usage example:
$ module start -f -p 42
)DESCR_STR");
PRINT_MODULE_USAGE_NAME("module", "template");
PRINT_MODULE_USAGE_COMMAND("start");
PRINT_MODULE_USAGE_PARAM_FLAG('f', "Optional example flag", true);
PRINT_MODULE_USAGE_PARAM_INT('p', 0, 0, 1000, "Optional example parameter", true);
PRINT_MODULE_USAGE_DEFAULT_COMMANDS();
return 0;
}
int control_node_main(int argc, char *argv[])
{
return ControlNode::main(argc, argv);
}
新建control_node.h，复制下面内容进去：
#pragma once
#include "commander/px4_custom_mode.h"
#include <px4_platform_common/module.h>
#include <px4_platform_common/module_params.h>
#include <uORB/Subscription.hpp>
#include <uORB/Publication.hpp>
#include <uORB/SubscriptionInterval.hpp>
#include <uORB/topics/parameter_update.h>
#include <uORB/topics/vehicle_local_position.h>
#include <uORB/topics/vehicle_local_position_setpoint.h>
#include <uORB/topics/vehicle_status.h>
#include <uORB/topics/home_position.h>
#include <uORB/topics/vehicle_command.h>
#include <uORB/topics/offboard_control_mode.h>
#include <uORB/topics/position_setpoint_triplet.h>
#include <uORB/topics/vehicle_command_ack.h>
#include <uORB/topics/vehicle_attitude_setpoint.h>
using namespace time_literals;
extern "C" __EXPORT int control_node_main(int argc, char *argv[]);
class ControlNode : public ModuleBase<ControlNode>, public ModuleParams
{
public:
ControlNode(int example_param, bool example_flag);
virtual ~ControlNode() = default;
/** @see ModuleBase */
static int task_spawn(int argc, char *argv[]);
/** @see ModuleBase */
static ControlNode *instantiate(int argc, char *argv[]);
/** @see ModuleBase */
static int custom_command(int argc, char *argv[]);
/** @see ModuleBase */
static int print_usage(const char *reason = nullptr);
/** @see ModuleBase::run() */
void run() override;
/** @see ModuleBase::print_status() */
int print_status() override;
private:
/**
* Check for parameter changes and update them if needed.
* @param parameter_update_sub uorb subscription to parameter_update
* @param force for a parameter update
*/
void parameters_update(bool force = false);
DEFINE_PARAMETERS(
(ParamInt<px4::params::SYS_AUTOSTART>) _param_sys_autostart, /**< example parameter */
(ParamInt<px4::params::SYS_AUTOCONFIG>) _param_sys_autoconfig /**< another parameter */
)
uint64_t time_tick=hrt_absolute_time();
int flag=0,flag2=0;
vehicle_local_position_s _vehicle_local_position;
vehicle_status_s _status;
vehicle_command_s _command = {};
offboard_control_mode_s ocm{};
position_setpoint_triplet_s _pos_sp_triplet{};
vehicle_command_ack_s _ack{};
vehicle_local_position_setpoint_s sp_local{};
vehicle_attitude_setpoint_s attitude_setpoint{};
// Subscriptions
uORB::SubscriptionInterval _parameter_update_sub{ORB_ID(parameter_update), 1_s};
uORB::Subscription _vehicle_local_position_sub{ORB_ID(vehicle_local_position)};
uORB::Subscription _vehicle_status_sub{ORB_ID(vehicle_status)};
// Publications
uORB::Publication<offboard_control_mode_s> _offboard_control_mode_pub{ORB_ID(offboard_control_mode)};
uORB::Publication<vehicle_command_s> _vehicle_command_pub{ORB_ID(vehicle_command)};
uORB::Publication<position_setpoint_triplet_s> _position_setpoint_triplet_pub{ORB_ID(position_setpoint_triplet)};
uORB::Publication<vehicle_local_position_setpoint_s> _trajectory_setpoint_pub{ORB_ID(trajectory_setpoint)};
};
添加到编译脚本
打开下图文件
添加一行
CONFIG_MODULES_CONTROL_NODE=y
二、测试
执行：
make px4_sitl_default gazebo
打开仿真后执行
control_node start
正常的话无人机会进入Offboard，并起飞到5米高然后按程序设定自主运动
更多推荐
19
0- 0
已为社区贡献6条内容
所有评论(0)
