Linux上下文切换时间精确测量方案

1. 方案架构：内核模块 + 微基准测试

2. 内核模块实现（核心）

// ctx_switch.c - 上下文切换时间测量内核模块
#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/init.h>
#include <linux/proc_fs.h>
#include <linux/sched.h>
#include <linux/sched/clock.h>
#include <linux/uaccess.h>
#include <linux/spinlock.h>
#include <linux/kthread.h>
#include <linux/delay.h>
#include <linux/version.h>
#include <linux/percpu.h>
#include <linux/hrtimer.h>
#include <linux/irqflags.h>
#include <linux/slab.h>
#include <linux/seq_file.h>
#include <linux/vmalloc.h>
#include <linux/cpumask.h>

#define MODULE_NAME "ctx_switch"
#define MAX_SAMPLES 100000
#define MAX_CPUS    NR_CPUS

// 上下文切换事件记录
struct ctx_switch_event {
    u64 switch_in_ts;      // 切换进入时间
    u64 switch_out_ts;     // 切换离开时间
    u64 switch_time_ns;    // 切换时间 = switch_in_ts - switch_out_ts
    pid_t prev_pid;        // 切换出的进程
    pid_t next_pid;        // 切换入的进程
    int cpu;               // CPU编号
    u32 seq;               // 序列号
    char prev_comm[TASK_COMM_LEN];  // 进程名
    char next_comm[TASK_COMM_LEN];
};

// 每个CPU的统计数据
struct per_cpu_stats {
    struct ctx_switch_event events[MAX_SAMPLES];
    unsigned int count;
    unsigned int head;
    unsigned int tail;
    spinlock_t lock;

    // 统计信息
    u64 min_ns;
    u64 max_ns;
    u64 total_ns;
    u64 total_sq_ns;  // 平方和，用于计算标准差

    // 当前切换状态
    u64 last_switch_out_ts;
    pid_t last_switch_out_pid;
    char last_switch_out_comm[TASK_COMM_LEN];

    // 活跃状态
    bool measuring;
};

// 全局变量
static struct per_cpu_stats __percpu *cpu_stats;
static struct proc_dir_entry *proc_entry;
static atomic_t module_active = ATOMIC_INIT(0);
static atomic_t test_seq = ATOMIC_INIT(0);
static struct task_struct *measure_threads[MAX_CPUS];

// 获取高精度时间戳
static inline u64 get_ns_timestamp(void)
{
#if LINUX_VERSION_CODE >= KERNEL_VERSION(4, 0, 0)
    return local_clock();
#else
    return sched_clock();
#endif
}

// 获取CPU周期计数（最高精度）
static inline u64 get_cycles(void)
{
#if defined(CONFIG_X86) || defined(CONFIG_X86_64)
    unsigned int low, high;
    asm volatile("rdtsc" : "=a" (low), "=d" (high));
    return ((u64)high << 32) | low;
#elif defined(CONFIG_ARM) || defined(CONFIG_ARM64)
    u64 val;
    asm volatile("mrs %0, cntvct_el0" : "=r" (val));
    return val;
#else
    return get_ns_timestamp();
#endif
}

// 记录上下文切换事件
static void record_ctx_switch(int cpu, pid_t prev_pid, const char *prev_comm,
                              pid_t next_pid, const char *next_comm,
                              u64 switch_out_ts, u64 switch_in_ts)
{
    struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);
    struct ctx_switch_event *event;
    unsigned long flags;
    u64 switch_time_ns;

    if (!stats || !stats->measuring)
        return;

    // 计算切换时间
    if (switch_in_ts < switch_out_ts) {
        // 处理回绕
        switch_time_ns = (U64_MAX - switch_out_ts) + switch_in_ts;
    } else {
        switch_time_ns = switch_in_ts - switch_out_ts;
    }

    // 过滤异常值（> 1ms的切换时间通常不是正常的上下文切换）
    if (switch_time_ns > 1000000)  // 1ms
        return;

    spin_lock_irqsave(&stats->lock, flags);

    // 使用环形缓冲区
    unsigned int idx = stats->head;

    event = &stats->events[idx];
    event->switch_out_ts = switch_out_ts;
    event->switch_in_ts = switch_in_ts;
    event->switch_time_ns = switch_time_ns;
    event->prev_pid = prev_pid;
    event->next_pid = next_pid;
    event->cpu = cpu;
    event->seq = atomic_read(&test_seq);
    strncpy(event->prev_comm, prev_comm, TASK_COMM_LEN - 1);
    strncpy(event->next_comm, next_comm, TASK_COMM_LEN - 1);
    event->prev_comm[TASK_COMM_LEN - 1] = '\0';
    event->next_comm[TASK_COMM_LEN - 1] = '\0';

    // 更新统计
    if (stats->count == 0) {
        stats->min_ns = switch_time_ns;
        stats->max_ns = switch_time_ns;
    } else {
        if (switch_time_ns < stats->min_ns)
            stats->min_ns = switch_time_ns;
        if (switch_time_ns > stats->max_ns)
            stats->max_ns = switch_time_ns;
    }

    stats->total_ns += switch_time_ns;
    stats->total_sq_ns += switch_time_ns * switch_time_ns;

    // 移动头指针
    stats->head = (stats->head + 1) % MAX_SAMPLES;
    stats->count++;

    // 如果缓冲区满，丢弃最旧数据
    if (stats->count > MAX_SAMPLES) {
        struct ctx_switch_event *old_event = &stats->events[stats->tail];

        // 从统计中移除旧数据
        stats->total_ns -= old_event->switch_time_ns;
        stats->total_sq_ns -= old_event->switch_time_ns * old_event->switch_time_ns;

        stats->tail = (stats->tail + 1) % MAX_SAMPLES;
        stats->count--;
    }

    spin_unlock_irqrestore(&stats->lock, flags);
}

// 调度器跟踪点处理（内核4.4+）
#if defined(CONFIG_TRACEPOINTS) && LINUX_VERSION_CODE >= KERNEL_VERSION(4, 4, 0)
#include <trace/events/sched.h>

// 调度切换事件
static void trace_sched_switch_handler(void *ignore,
                                      bool preempt,
                                      struct task_struct *prev,
                                      struct task_struct *next)
{
    int cpu = smp_processor_id();
    struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);
    u64 now = get_ns_timestamp();

    if (!stats || !stats->measuring)
        return;

    // 记录切换出的时间
    stats->last_switch_out_ts = now;
    stats->last_switch_out_pid = prev->pid;
    strncpy(stats->last_switch_out_comm, prev->comm, TASK_COMM_LEN - 1);
    stats->last_switch_out_comm[TASK_COMM_LEN - 1] = '\0';
}

// 唤醒事件（用于记录切换进入）
static void trace_sched_wakeup_handler(void *ignore, struct task_struct *p)
{
    int cpu = smp_processor_id();
    struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);

    if (!stats || !stats->measuring || stats->last_switch_out_ts == 0)
        return;

    u64 now = get_ns_timestamp();

    // 记录上下文切换
    record_ctx_switch(cpu,
                      stats->last_switch_out_pid,
                      stats->last_switch_out_comm,
                      p->pid,
                      p->comm,
                      stats->last_switch_out_ts,
                      now);

    // 重置
    stats->last_switch_out_ts = 0;
}
#endif

// 创建测量线程（用于主动触发上下文切换）
static int measure_thread_func(void *arg)
{
    int cpu = (long)arg;
    struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);
    struct sched_param param = { .sched_priority = 99 };
    cpumask_t mask;

    // 设置最高实时优先级
    sched_setscheduler(current, SCHED_FIFO, &param);

    // 绑定到指定CPU
    cpumask_clear(&mask);
    cpumask_set_cpu(cpu, &mask);
    set_cpus_allowed_ptr(current, &mask);

    pr_info("Context switch measurement thread started on CPU %d, PID %d\n",
            cpu, current->pid);

    stats->measuring = true;

    while (!kthread_should_stop()) {
        // 主动放弃CPU，触发上下文切换
        schedule();

        // 短暂睡眠，避免过度占用CPU
        msleep(1);
    }

    stats->measuring = false;
    return 0;
}

// 启动测量线程
static int start_measurement(void)
{
    int cpu;

    atomic_inc(&test_seq);

    for_each_online_cpu(cpu) {
        struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);
        char name[16];

        // 重置统计
        spin_lock(&stats->lock);
        stats->head = 0;
        stats->tail = 0;
        stats->count = 0;
        stats->min_ns = 0;
        stats->max_ns = 0;
        stats->total_ns = 0;
        stats->total_sq_ns = 0;
        stats->last_switch_out_ts = 0;
        spin_unlock(&stats->lock);

        // 创建测量线程
        snprintf(name, sizeof(name), "ctx_meas_%d", cpu);
        measure_threads[cpu] = kthread_create(measure_thread_func,
                                             (void *)(long)cpu,
                                             name);
        if (!IS_ERR(measure_threads[cpu])) {
            wake_up_process(measure_threads[cpu]);
        }
    }

    atomic_set(&module_active, 1);
    pr_info("Context switch measurement started\n");

    return 0;
}

// 停止测量
static void stop_measurement(void)
{
    int cpu;

    atomic_set(&module_active, 0);

    for_each_online_cpu(cpu) {
        if (measure_threads[cpu] && !IS_ERR(measure_threads[cpu])) {
            kthread_stop(measure_threads[cpu]);
            measure_threads[cpu] = NULL;
        }
    }

    pr_info("Context switch measurement stopped\n");
}

// 计算统计信息
static void calculate_stats(struct per_cpu_stats *stats,
                           u64 *min_ns, u64 *max_ns, u64 *avg_ns,
                           u64 *stddev_ns, u64 *p95_ns, u64 *p99_ns)
{
    unsigned long flags;
    unsigned int count;
    u64 *latencies;

    if (!stats || stats->count == 0) {
        *min_ns = *max_ns = *avg_ns = *stddev_ns = *p95_ns = *p99_ns = 0;
        return;
    }

    // 分配临时数组
    latencies = kmalloc(sizeof(u64) * stats->count, GFP_KERNEL);
    if (!latencies)
        return;

    // 复制数据
    spin_lock_irqsave(&stats->lock, flags);
    count = stats->count;

    unsigned int idx = stats->tail;
    for (unsigned int i = 0; i < count; i++) {
        latencies[i] = stats->events[idx].switch_time_ns;
        idx = (idx + 1) % MAX_SAMPLES;
    }

    *min_ns = stats->min_ns;
    *max_ns = stats->max_ns;
    *avg_ns = stats->total_ns / count;

    // 计算标准差
    u64 avg_sq = stats->total_sq_ns / count;
    u64 variance = avg_sq - (*avg_ns * *avg_ns);
    *stddev_ns = int_sqrt(variance);

    spin_unlock_irqrestore(&stats->lock, flags);

    // 排序计算百分位数
    sort(latencies, count, sizeof(u64), cmp_u64, NULL);
    *p95_ns = latencies[count * 95 / 100];
    *p99_ns = latencies[count * 99 / 100];

    kfree(latencies);
}

// 比较函数
static int cmp_u64(const void *a, const void *b)
{
    u64 la = *(const u64 *)a;
    u64 lb = *(const u64 *)b;

    if (la < lb) return -1;
    if (la > lb) return 1;
    return 0;
}

// /proc接口
static int proc_show(struct seq_file *m, void *v)
{
    int cpu;

    seq_printf(m, "=== Linux Context Switch Time Measurement ===\n\n");
    seq_printf(m, "Module status: %s\n",
               atomic_read(&module_active) ? "Active" : "Inactive");
    seq_printf(m, "Test sequence: %d\n\n", atomic_read(&test_seq));

    for_each_online_cpu(cpu) {
        struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);

        if (stats && stats->count > 0) {
            u64 min_ns, max_ns, avg_ns, stddev_ns, p95_ns, p99_ns;

            calculate_stats(stats, &min_ns, &max_ns, &avg_ns,
                          &stddev_ns, &p95_ns, &p99_ns);

            seq_printf(m, "CPU %d:\n", cpu);
            seq_printf(m, "  Samples:     %u\n", stats->count);
            seq_printf(m, "  Min:         %llu ns (%.3f us)\n",
                      min_ns, min_ns / 1000.0);
            seq_printf(m, "  Max:         %llu ns (%.3f us)\n",
                      max_ns, max_ns / 1000.0);
            seq_printf(m, "  Average:     %llu ns (%.3f us)\n",
                      avg_ns, avg_ns / 1000.0);
            seq_printf(m, "  StdDev:      %llu ns (%.3f us)\n",
                      stddev_ns, stddev_ns / 1000.0);
            seq_printf(m, "  95th %%ile:   %llu ns (%.3f us)\n",
                      p95_ns, p95_ns / 1000.0);
            seq_printf(m, "  99th %%ile:   %llu ns (%.3f us)\n",
                      p99_ns, p99_ns / 1000.0);
            seq_printf(m, "  Jitter:      %llu ns (%.3f us)\n\n",
                      max_ns - min_ns, (max_ns - min_ns) / 1000.0);

            // 显示最近几次切换
            seq_printf(m, "  Recent switches (last 5):\n");
            spin_lock(&stats->lock);
            unsigned int idx = (stats->head - 5 + MAX_SAMPLES) % MAX_SAMPLES;
            for (int i = 0; i < 5 && i < stats->count; i++) {
                struct ctx_switch_event *event = &stats->events[idx];
                seq_printf(m, "    %s(%d) -> %s(%d): %llu ns\n",
                          event->prev_comm, event->prev_pid,
                          event->next_comm, event->next_pid,
                          event->switch_time_ns);
                idx = (idx + 1) % MAX_SAMPLES;
            }
            spin_unlock(&stats->lock);
            seq_printf(m, "\n");
        }
    }

    return 0;
}

static int proc_open(struct inode *inode, struct file *file)
{
    return single_open(file, proc_show, NULL);
}

static ssize_t proc_write(struct file *file, const char __user *buf,
                         size_t len, loff_t *ppos)
{
    char cmd[64];

    if (copy_from_user(cmd, buf, min(len, sizeof(cmd)-1)))
        return -EFAULT;

    cmd[min(len, sizeof(cmd)-1)] = '\0';

    if (strncmp(cmd, "start", 5) == 0) {
        start_measurement();
    } else if (strncmp(cmd, "stop", 4) == 0) {
        stop_measurement();
    } else if (strncmp(cmd, "reset", 5) == 0) {
        int cpu;
        for_each_online_cpu(cpu) {
            struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);
            if (stats) {
                spin_lock(&stats->lock);
                stats->head = 0;
                stats->tail = 0;
                stats->count = 0;
                stats->min_ns = 0;
                stats->max_ns = 0;
                stats->total_ns = 0;
                stats->total_sq_ns = 0;
                spin_unlock(&stats->lock);
            }
        }
        pr_info("Statistics reset\n");
    }

    return len;
}

static const struct proc_ops proc_fops = {
    .proc_open = proc_open,
    .proc_read = seq_read,
    .proc_write = proc_write,
    .proc_lseek = seq_lseek,
    .proc_release = single_release,
};

// 模块初始化
static int __init ctx_switch_init(void)
{
    int cpu;

    pr_info("Context Switch Time Measurement Module Loading\n");

    // 分配per-CPU数据
    cpu_stats = alloc_percpu(struct per_cpu_stats);
    if (!cpu_stats)
        return -ENOMEM;

    // 初始化per-CPU数据
    for_each_online_cpu(cpu) {
        struct per_cpu_stats *stats = per_cpu_ptr(cpu_stats, cpu);

        spin_lock_init(&stats->lock);
        stats->head = 0;
        stats->tail = 0;
        stats->count = 0;
        stats->min_ns = 0;
        stats->max_ns = 0;
        stats->total_ns = 0;
        stats->total_sq_ns = 0;
        stats->last_switch_out_ts = 0;
        stats->measuring = false;

        measure_threads[cpu] = NULL;
    }

    // 创建/proc接口
    proc_entry = proc_create(MODULE_NAME, 0666, NULL, &proc_fops);
    if (!proc_entry) {
        free_percpu(cpu_stats);
        return -ENOMEM;
    }

    pr_info("Context Switch Time Measurement Module Ready\n");
    pr_info("Usage:\n");
    pr_info("  echo start > /proc/%s   # Start measurement\n", MODULE_NAME);
    pr_info("  echo stop > /proc/%s    # Stop measurement\n", MODULE_NAME);
    pr_info("  echo reset > /proc/%s   # Reset statistics\n", MODULE_NAME);
    pr_info("  cat /proc/%s           # View results\n", MODULE_NAME);

    return 0;
}

static void __exit ctx_switch_exit(void)
{
    stop_measurement();

    if (proc_entry)
        proc_remove(proc_entry);

    if (cpu_stats)
        free_percpu(cpu_stats);

    pr_info("Context Switch Time Measurement Module Unloaded\n");
}

module_init(ctx_switch_init);
module_exit(ctx_switch_exit);

MODULE_LICENSE("GPL");
MODULE_AUTHOR("Embedded Engineer");
MODULE_DESCRIPTION("Precise Linux Context Switch Time Measurement");

3. 用户空间微基准测试

// ctx_benchmark.c - 上下文切换基准测试
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>
#include <pthread.h>
#include <sched.h>
#include <time.h>
#include <sys/time.h>
#include <sys/syscall.h>
#include <sys/resource.h>
#include <sys/mman.h>
#include <errno.h>
#include <math.h>
#include <signal.h>
#include <fcntl.h>
#include <sys/stat.h>

#define DEFAULT_ITERATIONS 100000
#define DEFAULT_THREADS    2
#define DEFAULT_PRIORITY   99
#define PAGE_SIZE          4096

// 测试结果
struct test_results {
    double min_us;
    double max_us;
    double avg_us;
    double stddev_us;
    double p95_us;
    double p99_us;
    double p999_us;
    unsigned long *latencies_ns;
    unsigned int samples;
    unsigned int iterations;
};

// 共享数据（避免false sharing）
struct thread_data {
    pthread_t thread_id;
    int thread_num;
    int cpu_id;
    volatile int ready;
    volatile int go;
    volatile int stop;
    unsigned long *latencies;
    unsigned int count;
    pthread_barrier_t *barrier;
    pthread_mutex_t *mutex;
    pthread_cond_t *cond;
    char padding[64];  // 缓存行填充
} __attribute__((aligned(64)));

// 全局变量
static volatile int global_stop = 0;
static struct test_results global_results;

// 获取纳秒时间戳
static inline long long get_ns_timestamp(void)
{
    struct timespec ts;
    clock_gettime(CLOCK_MONOTONIC, &ts);
    return ts.tv_sec * 1000000000LL + ts.tv_nsec;
}

// 绑定到特定CPU
static void bind_to_cpu(int cpu_id)
{
    cpu_set_t cpuset;
    CPU_ZERO(&cpuset);
    CPU_SET(cpu_id, &cpuset);

    if (pthread_setaffinity_np(pthread_self(), sizeof(cpu_set_t), &cpuset) != 0) {
        perror("pthread_setaffinity_np");
    }
}

// 设置实时优先级
static void set_realtime_priority(int priority)
{
    struct sched_param param;
    param.sched_priority = priority;

    if (pthread_setschedparam(pthread_self(), SCHED_FIFO, &param) != 0) {
        if (errno == EPERM) {
            fprintf(stderr, "Warning: Need root for SCHED_FIFO priority %d\n", priority);
        } else {
            perror("pthread_setschedparam");
        }
    }
}

// 测试方法1：使用管道进行进程间上下文切换
static void *pipe_ctx_switch_test(void *arg)
{
    struct thread_data *data = (struct thread_data *)arg;
    int pipefd[2];
    char buffer = 'X';
    long long start_ns, end_ns;
    unsigned int idx = 0;

    // 创建管道
    if (pipe(pipefd) == -1) {
        perror("pipe");
        return NULL;
    }

    // 设置实时优先级
    set_realtime_priority(DEFAULT_PRIORITY);

    // 绑定到CPU
    bind_to_cpu(data->cpu_id);

    // 等待所有线程就绪
    pthread_barrier_wait(data->barrier);

    while (!data->stop && idx < data->count) {
        // 写入管道（触发上下文切换）
        start_ns = get_ns_timestamp();
        write(pipefd[1], &buffer, 1);

        // 读取管道（等待另一个进程）
        read(pipefd[0], &buffer, 1);
        end_ns = get_ns_timestamp();

        // 记录延迟（两次切换）
        data->latencies[idx] = (end_ns - start_ns) / 2;
        idx++;
    }

    close(pipefd[0]);
    close(pipefd[1]);

    return NULL;
}

// 测试方法2：使用互斥锁进行线程间上下文切换
static void *mutex_ctx_switch_test(void *arg)
{
    struct thread_data *data = (struct thread_data *)arg;
    long long start_ns, end_ns;
    unsigned int idx = 0;

    set_realtime_priority(DEFAULT_PRIORITY);
    bind_to_cpu(data->cpu_id);

    pthread_barrier_wait(data->barrier);

    while (!data->stop && idx < data->count) {
        pthread_mutex_lock(data->mutex);

        // 记录获取锁的时间
        start_ns = get_ns_timestamp();

        // 通知另一个线程
        data->ready = 1;

        // 等待另一个线程获取锁
        while (!data->go && !data->stop) {
            sched_yield();
        }
        data->go = 0;

        pthread_mutex_unlock(data->mutex);

        // 记录释放锁的时间
        end_ns = get_ns_timestamp();

        data->latencies[idx] = end_ns - start_ns;
        idx++;
    }

    return NULL;
}

// 测试方法3：使用条件变量
static void *condvar_ctx_switch_test(void *arg)
{
    struct thread_data *data = (struct thread_data *)arg;
    long long start_ns, end_ns;
    unsigned int idx = 0;

    set_realtime_priority(DEFAULT_PRIORITY);
    bind_to_cpu(data->cpu_id);

    pthread_barrier_wait(data->barrier);

    while (!data->stop && idx < data->count) {
        pthread_mutex_lock(data->mutex);

        // 等待条件变量
        start_ns = get_ns_timestamp();
        pthread_cond_wait(data->cond, data->mutex);
        end_ns = get_ns_timestamp();

        pthread_mutex_unlock(data->mutex);

        data->latencies[idx] = end_ns - start_ns;
        idx++;

        // 通知另一个线程
        usleep(1);
    }

    return NULL;
}

// 测试方法4：使用sched_yield主动放弃CPU
static void *yield_ctx_switch_test(void *arg)
{
    struct thread_data *data = (struct thread_data *)arg;
    long long start_ns, end_ns;
    unsigned int idx = 0;

    set_realtime_priority(DEFAULT_PRIORITY);
    bind_to_cpu(data->cpu_id);

    pthread_barrier_wait(data->barrier);

    while (!data->stop && idx < data->count) {
        start_ns = get_ns_timestamp();
        sched_yield();
        end_ns = get_ns_timestamp();

        data->latencies[idx] = end_ns - start_ns;
        idx++;

        // 避免过于频繁
        usleep(10);
    }

    return NULL;
}

// 计算统计信息
static void calculate_statistics(struct test_results *results)
{
    unsigned long long sum = 0, sum_sq = 0;
    unsigned long min = ULONG_MAX, max = 0;

    if (results->samples == 0)
        return;

    // 第一遍：基本统计
    for (unsigned int i = 0; i < results->samples; i++) {
        unsigned long latency = results->latencies_ns[i];
        sum += latency;
        sum_sq += latency * latency;
        if (latency < min) min = latency;
        if (latency > max) max = latency;
    }

    results->min_us = min / 1000.0;
    results->max_us = max / 1000.0;
    results->avg_us = (sum / results->samples) / 1000.0;

    // 计算标准差
    double avg_ns = (double)sum / results->samples;
    double variance = ((double)sum_sq / results->samples) - (avg_ns * avg_ns);
    results->stddev_us = sqrt(variance) / 1000.0;

    // 排序计算百分位数
    qsort(results->latencies_ns, results->samples,
          sizeof(unsigned long), compare_ulong);

    results->p95_us = results->latencies_ns[results->samples * 95 / 100] / 1000.0;
    results->p99_us = results->latencies_ns[results->samples * 99 / 100] / 1000.0;
    results->p999_us = results->latencies_ns[results->samples * 999 / 1000] / 1000.0;
}

// 比较函数
static int compare_ulong(const void *a, const void *b)
{
    unsigned long la = *(const unsigned long *)a;
    unsigned long lb = *(const unsigned long *)b;

    if (la < lb) return -1;
    if (la > lb) return 1;
    return 0;
}

// 运行上下文切换测试
static int run_ctx_switch_test(int test_type, int iterations, int num_threads)
{
    pthread_t *threads;
    struct thread_data *thread_data;
    pthread_barrier_t barrier;
    pthread_mutex_t mutex;
    pthread_cond_t cond;
    struct timespec start_ts, end_ts;
    double elapsed;

    printf("\n=== Context Switch Time Benchmark ===\n");
    printf("Test type:    %d\n", test_type);
    printf("Iterations:   %d\n", iterations);
    printf("Threads:      %d\n", num_threads);
    printf("Priority:     SCHED_FIFO %d\n", DEFAULT_PRIORITY);

    // 初始化同步对象
    pthread_barrier_init(&barrier, NULL, num_threads + 1);
    pthread_mutex_init(&mutex, NULL);
    pthread_cond_init(&cond, NULL);

    // 分配线程数据
    threads = calloc(num_threads, sizeof(pthread_t));
    thread_data = calloc(num_threads, sizeof(struct thread_data));

    // 分配结果数组
    global_results.samples = iterations;
    global_results.iterations = iterations;
    global_results.latencies_ns = calloc(iterations, sizeof(unsigned long));

    // 初始化线程数据
    for (int i = 0; i < num_threads; i++) {
        thread_data[i].thread_num = i;
        thread_data[i].cpu_id = i % sysconf(_SC_NPROCESSORS_ONLN);
        thread_data[i].ready = 0;
        thread_data[i].go = 0;
        thread_data[i].stop = 0;
        thread_data[i].latencies = global_results.latencies_ns + (i * iterations / num_threads);
        thread_data[i].count = iterations / num_threads;
        thread_data[i].barrier = &barrier;
        thread_data[i].mutex = &mutex;
        thread_data[i].cond = &cond;
    }

    // 创建线程
    for (int i = 0; i < num_threads; i++) {
        void *(*thread_func)(void *) = NULL;

        switch (test_type) {
            case 1: thread_func = pipe_ctx_switch_test; break;
            case 2: thread_func = mutex_ctx_switch_test; break;
            case 3: thread_func = condvar_ctx_switch_test; break;
            case 4: thread_func = yield_ctx_switch_test; break;
            default:
                fprintf(stderr, "Invalid test type\n");
                goto cleanup;
        }

        if (pthread_create(&threads[i], NULL, thread_func, &thread_data[i]) != 0) {
            perror("pthread_create");
            goto cleanup;
        }
    }

    // 等待所有线程就绪
    pthread_barrier_wait(&barrier);

    // 开始计时
    clock_gettime(CLOCK_MONOTONIC, &start_ts);

    // 运行测试
    sleep(1);  // 让测试运行一段时间

    // 停止测试
    global_stop = 1;
    for (int i = 0; i < num_threads; i++) {
        thread_data[i].stop = 1;
    }

    // 等待线程结束
    for (int i = 0; i < num_threads; i++) {
        pthread_join(threads[i], NULL);
    }

    // 结束计时
    clock_gettime(CLOCK_MONOTONIC, &end_ts);
    elapsed = (end_ts.tv_sec - start_ts.tv_sec) +
              (end_ts.tv_nsec - start_ts.tv_nsec) / 1e9;

    // 计算统计
    calculate_statistics(&global_results);

    // 输出结果
    printf("\n=== Test Results ===\n");
    printf("Duration:      %.2f seconds\n", elapsed);
    printf("Samples:       %u\n", global_results.samples);
    printf("Throughput:    %.1f switches/sec\n", global_results.samples / elapsed);
    printf("\nContext Switch Time:\n");
    printf("  Minimum:      %8.3f us\n", global_results.min_us);
    printf("  Maximum:      %8.3f us\n", global_results.max_us);
    printf("  Average:      %8.3f us\n", global_results.avg_us);
    printf("  Std Deviation:%8.3f us\n", global_results.stddev_us);
    printf("  95th %%ile:    %8.3f us\n", global_results.p95_us);
    printf("  99th %%ile:    %8.3f us\n", global_results.p99_us);
    printf("  99.9th %%ile:  %8.3f us\n", global_results.p999_us);
    printf("  Jitter:       %8.3f us\n", global_results.max_us - global_results.min_us);

    // 保存结果
    FILE *fp = fopen("ctx_switch_results.csv", "a");
    if (fp) {
        fprintf(fp, "%d,%d,%d,%.3f,%.3f,%.3f,%.3f,%.3f,%.3f,%.3f\n",
                test_type, iterations, num_threads,
                global_results.min_us, global_results.max_us, global_results.avg_us,
                global_results.stddev_us, global_results.p95_us, global_results.p99_us,
                global_results.p999_us, global_results.samples / elapsed);
        fclose(fp);
    }

cleanup:
    // 清理
    pthread_barrier_destroy(&barrier);
    pthread_mutex_destroy(&mutex);
    pthread_cond_destroy(&cond);
    free(threads);
    free(thread_data);
    free(global_results.latencies_ns);

    return 0;
}

// 信号处理
static void signal_handler(int sig)
{
    global_stop = 1;
    printf("\nTest interrupted by signal %d\n", sig);
}

int main(int argc, char *argv[])
{
    int test_type = 1;      // 1=pipe, 2=mutex, 3=condvar, 4=yield
    int iterations = DEFAULT_ITERATIONS;
    int num_threads = DEFAULT_THREADS;

    // 设置信号处理
    signal(SIGINT, signal_handler);
    signal(SIGTERM, signal_handler);

    // 解析参数
    for (int i = 1; i < argc; i++) {
        if (strcmp(argv[i], "-t") == 0 && i+1 < argc) {
            test_type = atoi(argv[++i]);
        } else if (strcmp(argv[i], "-n") == 0 && i+1 < argc) {
            iterations = atoi(argv[++i]);
        } else if (strcmp(argv[i], "-p") == 0 && i+1 < argc) {
            num_threads = atoi(argv[++i]);
        } else if (strcmp(argv[i], "-h") == 0) {
            printf("Usage: %s [options]\n", argv[0]);
            printf("Options:\n");
            printf("  -t <type>    Test type: 1=pipe, 2=mutex, 3=condvar, 4=yield (default: 1)\n");
            printf("  -n <iter>    Number of iterations (default: %d)\n", DEFAULT_ITERATIONS);
            printf("  -p <threads> Number of threads (default: %d)\n", DEFAULT_THREADS);
            printf("  -h           Show this help\n");
            return 0;
        }
    }

    // 检查root权限
    if (geteuid() != 0) {
        printf("Warning: Need root for real-time scheduling\n");
        printf("Running with normal priority...\n");
    }

    return run_ctx_switch_test(test_type, iterations, num_threads);
}

4. Shell脚本自动化测试

#!/bin/bash
# ctx_switch_bench.sh - 上下文切换时间自动化测试

ITERATIONS=100000
THREADS=2
OUTPUT_FILE="ctx_switch_results.txt"
CSV_FILE="ctx_switch_summary.csv"

echo "Linux Context Switch Time Benchmark"
echo "=================================="

# 1. 编译测试程序
echo -e "\n1. Compiling test programs..."
cat > ctx_benchmark.c << 'EOF'
// 简化的测试程序
#include <stdio.h>
#include <stdlib.h>
#include <pthread.h>
#include <time.h>
#include <sched.h>
#include <unistd.h>

#define ITERATIONS 100000

long long get_ns() {
    struct timespec ts;
    clock_gettime(CLOCK_MONOTONIC, &ts);
    return ts.tv_sec * 1000000000LL + ts.tv_nsec;
}

void *test_thread(void *arg) {
    long long *results = (long long *)arg;
    int count = ITERATIONS / 2;

    // 设置实时优先级
    struct sched_param param = { .sched_priority = 99 };
    sched_setscheduler(0, SCHED_FIFO, &param);

    for (int i = 0; i < count; i++) {
        long long start = get_ns();
        sched_yield();
        long long end = get_ns();
        results[i] = end - start;
        usleep(10);
    }

    return NULL;
}

int main() {
    pthread_t thread1, thread2;
    long long results1[ITERATIONS/2], results2[ITERATIONS/2];
    long long sum = 0, min = 1e9, max = 0;

    printf("Starting context switch test...\n");

    // 创建测试线程
    pthread_create(&thread1, NULL, test_thread, results1);
    pthread_create(&thread2, NULL, test_thread, results2);

    // 等待线程完成
    pthread_join(thread1, NULL);
    pthread_join(thread2, NULL);

    // 合并结果
    for (int i = 0; i < ITERATIONS/2; i++) {
        long long val = results1[i];
        sum += val;
        if (val < min) min = val;
        if (val > max) max = val;

        val = results2[i];
        sum += val;
        if (val < min) min = val;
        if (val > max) max = val;
    }

    double avg = (double)sum / ITERATIONS;

    printf("\nResults (2 threads, %d iterations):\n", ITERATIONS);
    printf("  Min:     %.3f us\n", min / 1000.0);
    printf("  Max:     %.3f us\n", max / 1000.0);
    printf("  Average: %.3f us\n", avg / 1000.0);
    printf("  Jitter:  %.3f us\n", (max - min) / 1000.0);

    return 0;
}
EOF

gcc -O2 -o ctx_benchmark ctx_benchmark.c -lpthread -lrt

# 2. 运行基本测试
echo -e "\n2. Running basic context switch test..."
sudo ./ctx_benchmark 2>&1 | tee $OUTPUT_FILE

# 3. 使用lmbench的lat_ctx测试
echo -e "\n3. Running lmbench lat_ctx (if available)..."
if command -v lat_ctx &> /dev/null; then
    echo "Testing with 2 processes..."
    lat_ctx -P 1 -s 0 2 2>&1 | grep -A5 "size"

    echo -e "\nTesting with varying process counts..."
    for procs in 2 4 8 16 32; do
        echo -n "Processes $procs: "
        lat_ctx -P 1 -s 0 $procs 2>&1 | tail -1
    done
fi

# 4. 使用perf stat测量上下文切换率
echo -e "\n4. Measuring context switch rate..."
echo "Running perf stat for 10 seconds..."
sudo perf stat -e context-switches,cpu-migrations -a sleep 10 2>&1 | grep -E "(context-switches|cpu-migrations|seconds)"

# 5. 不同负载下的测试
echo -e "\n5. Testing under different loads..."

# 空闲系统
echo -e "\nA. Idle system:"
sudo ./ctx_benchmark 2>&1 | tail -5

# CPU负载
echo -e "\nB. Under CPU load:"
stress-ng --cpu 4 --timeout 30s --quiet &
sleep 2
sudo ./ctx_benchmark 2>&1 | tail -5
killall stress-ng 2>/dev/null

# IO负载
echo -e "\nC. Under IO load:"
stress-ng --io 4 --timeout 30s --quiet &
sleep 2
sudo ./ctx_benchmark 2>&1 | tail -5
killall stress-ng 2>/dev/null

# 内存负载
echo -e "\nD. Under memory load:"
stress-ng --vm 2 --vm-bytes 512M --timeout 30s --quiet &
sleep 2
sudo ./ctx_benchmark 2>&1 | tail -5
killall stress-ng 2>/dev/null

# 6. 不同调度策略
echo -e "\n6. Testing different scheduling policies..."

for policy in "SCHED_OTHER" "SCHED_RR" "SCHED_FIFO"; do
    echo -e "\n$policy:"
    case $policy in
        "SCHED_OTHER")
            sudo chrt -o 0 ./ctx_benchmark 2>&1 | tail -5
            ;;
        "SCHED_RR")
            sudo chrt -r 50 ./ctx_benchmark 2>&1 | tail -5
            ;;
        "SCHED_FIFO")
            sudo chrt -f 99 ./ctx_benchmark 2>&1 | tail -5
            ;;
    esac
done

# 7. 生成报告
echo -e "\n7. Generating summary report..."
echo "Test Configuration:" > $CSV_FILE
echo "Date,Test,Iterations,Threads,Min(us),Max(us),Avg(us),Jitter(us)" >> $CSV_FILE

if [ -f $OUTPUT_FILE ]; then
    # 提取关键指标
    MIN_US=$(grep "Min:" $OUTPUT_FILE | awk '{print $2}')
    MAX_US=$(grep "Max:" $OUTPUT_FILE | awk '{print $2}')
    AVG_US=$(grep "Average:" $OUTPUT_FILE | awk '{print $2}')
    JITTER_US=$(grep "Jitter:" $OUTPUT_FILE | awk '{print $2}')

    echo "$(date),Basic,$ITERATIONS,$THREADS,$MIN_US,$MAX_US,$AVG_US,$JITTER_US" >> $CSV_FILE
    echo "Summary saved to $CSV_FILE"
fi

# 8. 使用内核模块（如果可用）
echo -e "\n8. Using kernel module (if loaded)..."
if [ -f /proc/ctx_switch ]; then
    echo "Starting measurement..."
    echo "start" | sudo tee /proc/ctx_switch > /dev/null
    sleep 5
    echo "Results:"
    sudo cat /proc/ctx_switch | head -20
    echo "stop" | sudo tee /proc/ctx_switch > /dev/null
else
    echo "Kernel module not loaded. To load: sudo insmod ctx_switch.ko"
fi

echo -e "\nTest complete! Results saved to $OUTPUT_FILE and $CSV_FILE"

5. 构建和使用

5.1 Makefile

# Makefile for context switch measurement
obj-m += ctx_switch.o

KDIR := /lib/modules/$(shell uname -r)/build
PWD := $(shell pwd)

CFLAGS_user := -O2 -Wall -lpthread -lrt

all: kernel user

kernel:
	$(MAKE) -C $(KDIR) M=$(PWD) modules

user:
	gcc $(CFLAGS_user) -o ctx_benchmark ctx_benchmark.c
	gcc $(CFLAGS_user) -o ctx_switch_test ctx_switch_test.c

clean:
	$(MAKE) -C $(KDIR) M=$(PWD) clean
	rm -f ctx_benchmark ctx_switch_test *.o

install:
	sudo insmod ctx_switch.ko
	sudo chmod 666 /proc/ctx_switch

uninstall:
	sudo rmmod ctx_switch

test:
	sudo ./ctx_benchmark
	sudo ./ctx_switch_test -t 1 -n 10000

.PHONY: all kernel user clean install uninstall test

5.2 使用步骤

# 1. 编译
make

# 2. 加载内核模块
sudo insmod ctx_switch.ko

# 3. 开始测量
echo "start" | sudo tee /proc/ctx_switch

# 4. 运行负载测试
stress-ng --cpu 4 --io 2 &

# 5. 查看结果
cat /proc/ctx_switch

# 6. 停止测量
echo "stop" | sudo tee /proc/ctx_switch

# 7. 运行用户空间测试
sudo ./ctx_benchmark
sudo ./ctx_switch_test -t 1 -n 100000 -p 4

# 8. 运行自动化测试
chmod +x ctx_switch_bench.sh
sudo ./ctx_switch_bench.sh

6. 专业工具和方法

6.1 使用lmbench

# 安装lmbench
sudo apt-get install lmbench

# 测试上下文切换时间
lat_ctx -s 0 2  # 2个进程
lat_ctx -s 0 4  # 4个进程
lat_ctx -s 0 8  # 8个进程

# 测试不同大小的进程
lat_ctx -s 64k 2  # 64KB数据大小
lat_ctx -s 1m 2   # 1MB数据大小

6.2 使用perf

# 测量上下文切换率
sudo perf stat -e context-switches,cpu-migrations -a sleep 10

# 跟踪上下文切换事件
sudo perf record -e sched:sched_switch -a sleep 10
sudo perf report

# 测量特定进程
sudo perf stat -e context-switches -p $(pidof my_app) sleep 5

6.3 使用systemtap

# systemtap脚本测量上下文切换时间
cat > ctx_switch.stp << 'EOF'
global switch_time, switch_count

probe scheduler.ctxswitch {
    switch_time[execname(), pid()] = gettimeofday_ns()
}

probe scheduler.ctxswitch.return {
    if (switch_time[execname(), pid()]) {
        delta = gettimeofday_ns() - switch_time[execname(), pid()]
        printf("%s (%d): %d ns\n", execname(), pid(), delta)
        switch_count++
        delete switch_time[execname(), pid()]
    }
}

probe end {
    printf("\nTotal context switches: %d\n", switch_count)
}
EOF

sudo stap ctx_switch.stp -c "sleep 10"

7. 优化建议

7.1 减少上下文切换时间

# 1. 使用CPU亲和性
taskset -c 0,1 ./my_app  # 绑定到CPU 0和1

# 2. 使用实时优先级
chrt -f 99 ./my_app

# 3. 减少进程数量
# 合并功能相似的进程

# 4. 使用线程代替进程
# 线程切换比进程切换更快

# 5. 调整调度器参数
echo 1000000 > /proc/sys/kernel/sched_min_granularity_ns
echo 10000000 > /proc/sys/kernel/sched_wakeup_granularity_ns

# 6. 禁用NUMA平衡
echo 0 > /proc/sys/kernel/numa_balancing

# 7. 使用大页
echo 2048 > /sys/kernel/mm/hugepages/hugepages-2048kB/nr_hugepages

7.2 内核配置优化

# 检查当前配置
grep -E "CONFIG_PREEMPT|CONFIG_HZ|CONFIG_NO_HZ" /boot/config-$(uname -r)

# 推荐配置
CONFIG_PREEMPT=y          # 内核抢占
CONFIG_PREEMPT_RT=y       # 实时内核（可选）
CONFIG_HZ=1000           # 1000Hz定时器
CONFIG_NO_HZ_IDLE=y      # 空闲时停止定时器
CONFIG_NO_HZ_FULL=y      # 完全无滴答（减少中断）

8. 结果解读指南

8.1 性能等级参考

< 1us     : 优秀（缓存命中，CPU亲和性好）
1-5us     : 良好（正常Linux系统）
5-20us    : 一般（可能有调度器压力）
20-50us   : 较差（系统负载高）
> 50us    : 差（需要优化）

8.2 关键影响因素

1. CPU缓存状态：L1/L2/L3缓存命中率
2. TLB状态：页表缓存命中率
3. 调度器开销：调度决策时间
4. 内存访问模式：局部性原理
5. 系统负载：其他进程的干扰

8.3 典型测试场景结果

# 测试结果示例
=== Context Switch Time Results ===

Scenario 1: Idle system, 2 threads, SCHED_FIFO
----------------------------------------------
Min:     0.8 us    # 最佳情况
Average: 1.2 us    # 典型值
P99:     2.8 us    # 99%的切换时间
Max:     5.6 us    # 最坏情况
Jitter:  4.8 us    # 变化范围

Scenario 2: Under CPU load (4 cores 100%)
----------------------------------------------
Min:     1.2 us
Average: 3.8 us
P99:     12.4 us
Max:     25.6 us
Jitter:  24.4 us

Scenario 3: Different process counts (lmbench)
----------------------------------------------
2 processes:   1.5 us
4 processes:   2.1 us
8 processes:   3.8 us
16 processes:  7.2 us
32 processes: 14.5 us

9. 综合评估脚本

#!/bin/bash
# context_switch_eval.sh - 上下文切换综合评估

echo "Context Switch Time Comprehensive Evaluation"
echo "=========================================="

# 1. 系统信息
echo -e "\n1. System Information:"
echo "Kernel: $(uname -r)"
echo "CPU: $(grep "model name" /proc/cpuinfo | head -1 | cut -d: -f2)"
echo "Cores: $(grep -c "^processor" /proc/cpuinfo)"
echo "Memory: $(free -h | grep Mem | awk '{print $2}')"

# 2. 当前上下文切换率
echo -e "\n2. Current Context Switch Rate:"
sudo vmstat 1 5 | tail -4 | awk '{print $12 " cs/sec"}'

# 3. 使用不同工具测试
echo -e "\n3. Cross-Validation with Multiple Tools:"

# 使用lmbench
if command -v lat_ctx &> /dev/null; then
    echo -e "\nA. lmbench lat_ctx:"
    for procs in 2 4 8; do
        echo -n "  $procs processes: "
        lat_ctx -s 0 $procs 2>&1 | tail -1 | awk '{print $2 " us"}'
    done
fi

# 使用perf
echo -e "\nB. perf stat (10 seconds):"
sudo perf stat -e context-switches,cpu-migrations -a sleep 10 2>&1 | \
    grep -E "(context-switches|cpu-migrations|seconds)" | \
    awk '{printf "  %s: %s\n", $2, $1}'

# 4. 不同负载测试
echo -e "\n4. Load Impact Analysis:"

load_tests=("idle" "cpu" "io" "memory")
for test in "${load_tests[@]}"; do
    echo -e "\n  $test load:"

    case $test in
        "cpu")
            stress-ng --cpu 4 --timeout 20s --quiet &
            LOAD_PID=$!
            sleep 2
            ;;
        "io")
            stress-ng --io 4 --timeout 20s --quiet &
            LOAD_PID=$!
            sleep 2
            ;;
        "memory")
            stress-ng --vm 2 --vm-bytes 512M --timeout 20s --quiet &
            LOAD_PID=$!
            sleep 2
            ;;
    esac

    # 运行测试
    if [ -f ./ctx_benchmark ]; then
        sudo ./ctx_benchmark 2>&1 | grep -E "(Min:|Max:|Average:|Jitter:)" | \
            while read line; do echo "    $line"; done
    fi

    # 清理负载
    if [ ! -z "$LOAD_PID" ]; then
        kill $LOAD_PID 2>/dev/null
        wait $LOAD_PID 2>/dev/null
    fi
done

# 5. 优化建议
echo -e "\n5. Optimization Recommendations:"

# 检查当前配置
echo -e "\n  Current configuration:"
echo -n "  Kernel preemption: "
if grep -q "CONFIG_PREEMPT=y" /boot/config-$(uname -r) 2>/dev/null; then
    echo "Enabled"
else
    echo "Disabled (consider enabling)"
fi

echo -n "  HZ: "
grep "CONFIG_HZ=" /boot/config-$(uname -r) 2>/dev/null | cut -d= -f2

echo -n "  CPU isolation: "
if grep -q "isolcpus" /proc/cmdline; then
    echo "Enabled"
else
    echo "Disabled (consider isolating CPUs)"
fi

# 6. 生成报告
echo -e "\n6. Summary Report:"
echo "=================="
echo "For real-time applications:"
echo "- Target context switch time: < 10us"
echo "- Monitor P99 latency (not just average)"
echo "- Consider using CPU isolation"
echo "- Use SCHED_FIFO for critical tasks"
echo "- Monitor system load regularly"
echo "- Consider PREEMPT_RT for hard real-time"

echo -e "\nEvaluation complete!"

总结

这个完整的上下文切换时间测量方案提供：

核心特性

1. 多种测量方法：管道、互斥锁、条件变量、yield
2. 内核模块：精确跟踪调度器事件
3. 用户空间工具：灵活的基准测试
4. 自动化脚本：一键测试和分析
5. 专业工具集成：lmbench、perf、systemtap

关键指标

• 平均切换时间：系统典型性能
• P99/P999延迟：最坏情况保障
• 抖动：性能稳定性
• 不同负载下的表现：真实场景评估

适用场景

• 实时系统评估：验证是否满足实时性要求
• 性能调优：识别上下文切换瓶颈
• 系统比较：不同硬件/内核配置对比
• 容量规划：确定系统能支持的并发任务数

最佳实践

1. 组合使用多种工具进行交叉验证
2. 测试不同负载场景（空闲、CPU、IO、内存）
3. 关注百分位数而不仅是平均值
4. 监控长期趋势而不仅是单次测试
5. 结合业务场景设定合理的目标值

通过这个方案，您可以全面、精确地测量Linux系统的上下文切换时间，为系统优化和实时性评估提供可靠数据支持。
